SIRMAN – SO 2400 INOX

Sirman-Banner

Technical Data



Model

SO 2400 INOX

Blade length

mm 2400

Motor

1ph – Hp 2 / rpm 900
3ph – Hp 2,4 / rpm 900

Ø Pulley

mm 300

Working surface

mm 575×705

A

mm 444

B

mm 524

C

mm 715

D

mm 750

E

mm 840

F

mm 1170

G

mm 1670

H

mm 350

L

mm 287

M

mm 897

Net weight

Kg 115

Shipping

mm 1050x950x1960

Gross weight

Kg 125

HS-CODE

84385000

FEATURES:

  • Sirman Bone Saws , model SO 2400 Inox :
  •  AISI 304 stainless steel body.
  •  Interlocking scrap pan accessible from the outside.
  • Easily removable door to facilitate cleaning.
  •  Calibrated pulleys made of polished aluminium.
  •  Sealed bearings on upper pulley.
  •  Powerful asynchronous and ventilated motors protected by lip seals.
  •  Controls (24 V) with safety micro-switch on door and pan, redundancy control unit and motor brake (CE).
  •  Upper pulley with quick-release mechanism to facilitate cleaning and blade change.
  •  Easily removable and replaceable scrapers.
  •  Powerful 6- and 8-pole motors generate considerable force with limited power input.
  •  Single-phase motors with standard thermal protection.
  •  Washable with water jet (no high pressure).
  •  IP 67 stainless steel controls
  •  Equipped with 16 mm tempered blades for cutting bones, frozen foods and fresh foods.Optional elements:
  •  Sliding carriage.
  •  High-speed motors designed for cutting frozen foods.
  •  Pulley with AISI 304 stainless steel edging.

Alimentary plastic blade scraper in quick to insert.

Hermetic upper pulley
